| Company | Trenz Electronic GmbH |
|---|---|
| PCN Number | PCN-20240705 |
| Title | TE0703-07 Assembly pull-down resistor R36. |
| Subject | Assembly pull-down resistor R36. |
| Issue Date | 2024-07-22 |
Products Affected
This change affects all Trenz Electronic TE0703-07 with a serial number greater than 915226.
Changes
#1 Assembly pull-down resistor (R36).
Type: BOM Change
Reason: Do not allow floating signal "OTG_ID" for host only applications.
Impact: None.
Method of Identification
The model code and revision number (TE0703-07) are printed on the top side of the PCB. The serial number is written at the QR-code on the bottom side label.
Production Shipment Schedule
With immediate effect this change takes place. If the changed product is not suitable for your application and still the former product of the board is needed, please contact us.
Contact Information
If you have any questions related to this PCN, please contact Trenz Electronics Technical Support at
- forum.trenz-electronic.de
- wiki.trenz-electronic.de
- support%trenz-electronic.de (subject = PCN-20240705)
phone
national calls: 05741 3200-0
international calls: 0049 5741 3200-0
Disclaimer
Any projected dates in this PCN are based on the most current product information at the time this PCN is being issued, but they may change due to unforeseen circumstances. For the latest schedule and any other information, please contact your local Trenz Electronic sales office, technical support or local distributor.
This PCN follows JEDEC Standard J-STD-046.
