| Company | Trenz Electronic GmbH |
|---|---|
| PCN Number | PCN-20250324 |
| Title | KK0745-02 to KK0745-03 Hardware Revision |
| Subject | Hardware Revision |
| Issue Date | 2025-05-09 |
Products Affected
This change affects all Trenz Electronic KK0745-02 heat spreader: KK0745-02*.
Affected Product | Replacement |
|---|---|
| KK0745-02 | KK0745-03 |
Changes
#1 Optimized for TE0745-03.
Type: Hardware change
Reason: TE0745 Revision Update.
Impact: Not compatible with TE0745-02.
Method of Identification
Models with these holes marked in red are KK0745-03.
Production Shipment Schedule
This change takes place with immediate effect. If the new model is not suitable for your application and still the former model of the heat spreader is needed, please contact us.
Contact Information
If you have any questions related to this PCN, please contact Trenz Electronics Technical Support at
- forum.trenz-electronic.de
- wiki.trenz-electronic.de
- support%trenz-electronic.de (subject = PCN-20250324)
phone
national calls: 05741 3200-0
international calls: 0049 5741 3200-0
Disclaimer
Any projected dates in this PCN are based on the most current product information at the time this PCN is being issued, but they may change due to unforeseen circumstances. For the latest schedule and any other information, please contact your local Trenz Electronic sales office, technical support or local distributor.
This PCN follows JEDEC Standard J-STD-046.
