Overview


Power supply

Over MicroUSB (5V) possible.

DIP-Switches

There are no DIPs on TE0722. In case of TE0790 (XMOD) usage, see power supply section.

LEDs

D2(red): User LED connected to MIO9

D6(green): User LED connected to G14

D7(green): 3.3V Power LED

JTAG/UART

JTAG and UART is possible over miro USB connector.

miroUSB UART is connected to PL IO (RX: Pin H13, TX: Pin H14).
