| Company | Trenz Electronic GmbH |
|---|---|
| PCN Number | PCN-20200330 |
| Title | TE0630-02 SPI Flash Change |
| Subject | BOM change |
| Issue Date | 2020-04-06 |
Products Affected
This change affects all Trenz Electronic TE0630 SoMs of revision 02: TE0630-02*.
Changes
#1 Change SPI Flash from W25Q64FVZPIG to W25Q64JVZPIQ
Type: BOM Change
Reason: W25Q64FVZPIG SPI Flash is obsolete.
Impact: None. Both have same JEDEC ID 9Fh and manufacturer ID 90h.
Method of Identification
Locate Flash (U14) on bottom side of PCB:
old | new |
|---|---|
W25Q64FVZPIG | W25Q64JVZPIQ |
|
|
Production Shipment Schedule
Changed versions will be shipped from June 2020 after old stock is gone. Modules with serial number greater than 639820 are assembled with the new flash.
Contact Information
If you have any questions related to this PCN, please contact Trenz Electronics Technical Support at
- forum.trenz-electronic.de
- wiki.trenz-electronic.de
- support%trenz-electronic.de (subject = PCN-20200330)
phone
national calls: 05741 3200-0
international calls: 0049 5741 3200-0
Disclaimer
Any projected dates in this PCN are based on the most current product information at the time this PCN is being issued, but they may change due to unforeseen circumstances. For the latest schedule and any other information, please contact your local Trenz Electronic sales office, technical support or local distributor.
This PCN follows JEDEC Standard J-STD-046.
